How Gardyn's water system works: pump, tank and flow

Gardyn works by storing water and plant food in a tank at the base, then using a pump under the lid to push that solution up hoses inside each column. The water trickles down past every yCube and drains back into the tank, so the same supply recirculates on a programmed schedule while sensors and cameras keep watch.

That loop sounds more complicated than it is. This guide walks through each part, from the tank to the top of the columns and back, plus the simple routine that keeps it running.

Key takeaways

• The tank sits at the bottom, and a pump in a holder under the lid moves water from the tank into hoses that run up each column.
• Water exits at the top of each column, trickles down past the yCubes and drains back into the tank, which makes the system recirculating.
• A water level sensor, a temperature and humidity sensor and built-in cameras give Kelby the information it needs to manage watering and send alerts.
• Your part is a weekly top-off between refreshes and a full tank refresh and clean at least every 4 weeks.
• If the pump ever stops, you can water by hand with a cup until the issue is fixed.

What are the main parts of the Gardyn water system?

Gardyn Home and Gardyn Studio share the same layout: the tank at the bottom, the lid in the middle and the columns above.

The main power switch sits on the rear of the water tank.

How does water get from the tank to the plants?

When a watering cycle starts, the pump switches on and draws solution up from the tank. It sends that water through a large hose attached to the pump's outlet, then into a splitter that divides the flow among the columns.

Each column has its own irrigation hose. It connects to the lid at the base of the column and runs up the inside to the top module. At the top, the hose arches downward so water spills into the column instead of spraying out. From there, gravity takes over. The water trickles down through the column, wetting each yCube on the way.

When the water reaches the bottom, it drains straight back into the tank for the next cycle. This style of design is called a recirculating system. Virginia Cooperative Extension describes the same loop in commercial hydroponics, where a collection system "returns the solution to the reservoir where it is again pumped to the plants."

Gardyn calls its overall growing approach Hybriponic technology. The water loop described here is the hardware that makes it work day to day.

Who decides when the pump runs?

You can choose how much control you want. The water tile in the Gardyn app shows one of three modes:

• Smart (Smart Watering). Kelby manages the watering schedule and adjusts it as your plants grow from seedlings to mature plants.
• Auto (Schedule Mode). The pump follows a schedule you set. The tile shows your next watering start time, and you can edit, add or copy cycles across days.
• Manual. You start every cycle yourself.

In any mode, you can run a cycle on demand by switching the Watering toggle on. A manual cycle stops when you switch it off or after 15 minutes, whichever comes first.

During the first soak after setup, the Gardyn enters Germination Mode, and Kelby controls watering to help seeds sprout. It is normal to go a few days without hearing another cycle during this stage.

If your Wi-Fi drops, the garden keeps going. It follows the last schedules saved before the connection was lost, though you cannot adjust them in the app until it reconnects.

What do the sensors and cameras add?

The water level sensor on the underside of the lid reports the tank level to the water tile on the app's home screen. The tile can show a WATER LOW badge when it is time to add water and an OVERFILLED badge when the tank holds more than it should. After you top off or refill, the sensor can take 30 minutes to an hour to settle on an accurate reading, so a brief odd number right after filling is normal.

The temperature and humidity sensor tracks the conditions around the garden. That matters heading into winter, when indoor heating can change the air in a room.

Built-in cameras take a photo every half hour. Kelby uses those images, along with the sensor readings, to confirm your first watering was successful, check assembly and send step-by-step tasks in the app. For a closer look at how that detection works, see our guide to how AI plant monitoring works.

What is the weekly and monthly water routine?

Your job comes down to two habits.

Top off weekly between refreshes. Plants use water as they grow, so the level in the tank drops over time. Between refreshes, add water and plant food together, gallon by gallon, to keep the tank full and the mix steady. The dose depends on growth stage: 1/2 tsp per gallon during vegetative growth and 1 tsp per gallon for mature, blooming or fruiting plants.

Refresh and clean the tank at least every 4 weeks. A refresh means fully draining the tank, cleaning it and refilling it with fresh water and the right plant food dose. The basic steps are:

1. Power off and unplug the garden, lay a towel down and raise the pump to its upper position.
2. Unlock the lid and lift the upper half by the columns (not the lights), resting it on the towel.
3. Drain the tank and clean it with water, a soft sponge and baking soda. Skip the soap.
4. Refill one gallon at a time, mixing warm tap water with the correct plant food dose in a clean container first.
5. Reattach the top, lower the pump, lock the lid and power on. The reboot takes about 5 minutes.
6. Log the refresh in the app so your next one is scheduled.

The app's water widget shows a refresh reminder 7 days before it is due, turning orange when it is coming soon and red when it is due or overdue. Members also get a Kelby task. For a realistic look at how much time all of this takes across a week, read Gardyn maintenance: exactly how much work it actually takes.

What if water stops flowing?

Most watering issues trace back to the pump or a hose:

• You cannot hear the pump. Run a cycle from the app and listen. If nothing happens, reboot the garden at the main switch, wait 5 minutes and try again. If it is still quiet, move the pump up and down in its holder a few times. Low water can trap air in the pump, and this can clear it.
• Only the bottom yCubes are wet. The column hose may have come loose from the lid. Check that the connector at the base of the column is pushed down snugly.
• Water sprays out the top of a column. The hose in the top module needs to be repositioned so it arches down into the column.

While you troubleshoot, you can water by hand. Pour a cup at a time of water and plant food into the top of each column until it drains into the tank. Gardyn support can help if a part needs replacing. Our guide to troubleshooting common hydroponic problems covers plant-side issues too.

Ready to see the whole system in action? See how Gardyn works.

Frequently asked questions

Does the water in a Gardyn recirculate?

Yes. The pump sends water up each column, and it drains back down into the tank after passing the yCubes. The same supply is reused cycle after cycle until your next tank refresh.

Where is the pump in a Gardyn?

The pump sits under the lid in a white plastic holder. You raise it to its upper position before draining the tank and lower it again after you put the garden back together.

How often should I refresh the tank?

Gardyn recommends a full drain, clean and refill at least every 4 weeks, with weekly top-offs in between. The app reminds you 7 days before a refresh is due.

Can I control when my Gardyn waters?

Yes. You can let Kelby manage watering with Smart Watering, set your own schedule in Schedule Mode or start each cycle yourself in Manual Mode.

What happens to watering if my Wi-Fi goes down?

The garden keeps following the last schedules saved before the connection dropped. You can adjust schedules again once it reconnects.
